Slider Type

Feature :

– Used for transporting and positioning work pieces
– 24V pulse and 24V/240V servo motor versions
– Strokes up to 1200mm and speeds up to 1800mm/S

Rod Type

Feature :

– Used for pushing, positioning, lifting or parts insertion
– 24V pulse and 24V/240V servo motor versions
– Strokes up to 500mm and speeds up to 800mm/S

Table Type

Feature :

– Used for applications similar to the rod, but with axial loading capability
– 24V pulse and 24V/240V servo motor versions
– Strokes up to 200mm and speeds up to 600mm/S

Rotary Type

Feature :

– Used for high speed rotational positioning or index tables
– 24V pulse and 240V servo motor versions
– Built in gearing and multiple rotation capability
– Servo version allows ±0.005º repeatability at 800º/sec

Gripper Type

Feature :

-bUsed to grip or centre product, or on cartesian and arm robots
– 24V pulse motor, slide or lever action types
– Up to 100mm stroke or 180º movement with various grip forces

Mini Type

Feature :

– Rod and table types in size and shape similar to air cylinders
– 24V pulse and 24V/240V servo motor versions
– Stroke of 30/50/75mm on rod type and up to 100mm on table type
– Lead and ball screw options determining the thrust force available

Industrial Robot

Feature :

This is the enhanced third generation of IAI’s most popular series of linear actuator. The series incorporates a number of major design innovations which have greatly enhanced the performance.

The ISB series uses ball-screw drive to ensure a long service life and accurate positioning.
Embedded carriage guide rails within a high rigidity hollow box structure base allow the actuators to handle significant load moments without the need for external guide rails.

Cartesian Robot

Feature :

The ICSA/ICSPA Cartesian robots are configuration units based on the two-axes and three-axes configuration patterns that
are frequently used. These actuators come pre-wired with brackets attached, so they can be installed in your equipment and
used immediately after delivery.

Table Top Robot

Feature :

The TTA series provides a high performance, competitively priced and easy to use table-top robot, with excellent positioning repeatability of just ±0.02mm.

A choice of 2- or 3-axes versions and gate or cantilever configurations make them suitable for applications such as soldering, coating, circuit board inspection or driving screws.

The simple programming allows the easy development of 3-axes arc interpolated, and PATH moves.

IAI SCARA robot Robot

Feature :

NNN Series  –  Standard Type

The standard type combines the best performance and user-friendliness in it’s class. The selectable arm length (250mm to 1200mm) provides the flexibility to suit a wide range of applications.

Wall Type SCARA Robot

Feature :

This robot is mounted on a wall for
operation. The space below the
robot can be utilized effectively, so
you will have more freedom in
designing your equipment.

PowerCon SCARA Robot

Feature :

Introducing Arm Lengths

180/250/550/650 Added in
Cost-effective IXP Series,
Giving More Variations to the Lineup

The simple programming allows the easy development of 3-axes arc interpolated, and PATH moves.
